Floor type inverter Midea MFA2U-12HRFNX-QRD0W

109.000,00 L

Garanci 36 muaj

Fuqia

Gazi/Freoni

Klasi Energjitik

Kompresori

Siperfaqe

SKU: floor-12 Kategori: , Etiketë:

Përshkrim

• Hepa filter, captures small particles of dust, bacteria and microbes that walk in the air
• Economic mode
• Night mode
• Silent airflow
• Air inflation in two directions, one upper and lower simultaneously, or only higher
• Cable remote control with wifi function (Optional)
• On/Off connection, alarm and centralized by installing a multifunction board
• Indoor units compatible with the Multi-split range
• Possibility of connecting to the centralized controller CCMC9, CCM15 or CCM30
• Arctic Fox Remote Control
• Anti-corrosion treatment “Golden Fin”
• Warranty 36 months

Pershkrimi Informacione

Pershkrimi

Turbo mode

When Turbo mode is activated, the indoor unit fan starts running at maximum speed to ensure the desired temperature as quickly as possible. The mode lasts a maximum of 20 minutes, after which it automatically returns to the preset mode before activating Turbo mode.

Night mode

When night mode is activated during cooling, the air conditioner automatically raises the room temperature by 1 ° C for the first two hours, after which it remains fixed. When night mode is activated during heating, the air conditioner automatically lowers the room temperature by 1 ° C for the first two hours, after which it remains fixed.

Quiet mode

The indoor unit fan runs at very low speeds, reducing noise and providing peace and quiet.

Automatic restart

In the event that the air conditioner stops working unexpectedly due to a power outage, it will restart automatically as soon as power is restored and will start operating in the mode set before the power was turned off.

24-hour timer

Ability to set a 24-hour timer to turn the air conditioning system on and off within 24 hours.

Tabela e Produkteve

Avarage Pdesignc

3.5 kW

Avarage SEER

7.3 W/W

Avarage Energy Efficiency Class

A++

Avarage Pdesignh

2.6 kW

Avarage SCOP

4.0 W/W

Avarage Energy Efficiency Class

A+

Avarage Tbiv

-7 ℃

Warmer Pdesignh

3.4 kW

Warmer SCOP

5.5 W/W

Warmer Energy Efficiency Class

A+++

Warmer Tbiv

2 ℃

Tol

-15 ℃

Power supply (Indoor )

220-240V,1Ph，50Hz

Power supply (Outdoor )

220-240V,1Ph，50Hz

Cooling Capacity

12000（2600~14500) Btu/h

Cooling Capacity

3.52(0.76~4.25) kW

Cooling Input

1000（170~1350) W

Cooling Current

4.52（1.4~5.9) A

Heating Capacity

13000（1550~16000) Btu/h

Heating Capacity

3.81(0.45~4.69) kW

Heating Input

980（150~1300)

Indoor fan motor Model

/

Indoor fan motor Old Model

2

Indoor fan motor Input

21*2 W

Indoor fan motor Capacitor

/ uF

Indoor fan motor Speed(Hi/Mi/Lo)

992/884/776 r/min

Indoor coil Number of rows

2

Indoor coil Tube pitch(a)x row pitch(b)

21x13.37 mm

Indoor coil Fin spacing

1.3 mm

Indoor coil Fin type (code)

Hydrophilic aluminum mm

Indoor coil Tube outside dia.and type

Φ7,Inner groove tube mm

Number of circuits

2

Indoor air flow (Hi/Mi/Lo)

650/580/490 m3/h

Indoor sound pressure level(Hi/Mi/Lo/Si)

37/34/27 dB(A)

Indoor sound power level (Hi)

54 dB(A)

Outdoor sound pressure level

54 dB(A)

Outdoor sound power level (Hi)

62 dB(A)

Indoor unit Dimension(W*D*H)

794x206x621 mm

Indoor unit Packing (W*D*H)

865x280x719 mm

Indoor unit Net/Gross weight

14.9/18.8 kg

Design pressure

4.3/1.7 MPa

Drainage water pipe dia.

ODΦ16mm mm

Refrigerant piping Liquid side/ Gas side

6.35mm(1/4in)/9.52mm(3/8in)

Controller

Remote Control

Operation temperature

16-30 ℃

Room temperature Cooling

16-32 ℃

Room temperature Heating

0-30 ℃

Qty’per 20’ /40’ /40'HQ

168/344/390
